Genuin FS 5

Produktion 2011-2013

Produced 2011-2013

Produzione 2011-2013

High End Bookshelf and Desktop speaker: for high end people

High End Schreibtisch- und Regallautsprecher: fr High Ender

High End da scaffale e scrivania: per gli amanti della musica


Alt image
Blumenhofer Acoustics Genuin FS 5
Lot of people like to listen to the music at work, where they do not have space for a stand loudspeaker.
We built this bookshelf or desktop speaker based on the experience made with the Genuin FS 4.2, the Genuin FS 5 shares the same character and the same sound of the bigger brother. Adapted for the desktop and bookshelf environment.
The components used for the Genuin FS 5 are exactly the same like the ones of the Genuin FS 4. The only difference are the dimension, 12 litres instead of 15 and the foot.

Specifications of the Genuin FS 5

Spezifikationen der Genuin FS 5

Specifiche della Genuin FS 5

2-Ways loudspeaker

Cabinet


Rear ported Bass-Reflex
• 18mm Birch plywood
• High complex internal bracing

Components


• 1" Compression Driver with Mylar membrane
• 17cm (6") Woofer with P2C® Membran

Features


• Single-wiring-terminals
• 10 years Warranty

Technical data of the Genuin FS 5

Technische Daten der Genuin FS 5

Dati tecnici della Genuin FS 5

Genuin FS 5
MaterialMaterialMateriale:Birch plywoodBirke MultiplexMultistrato di betulla
ThicknessMaterialdickeSpessore:18mm / 0,75"
Internal BracingVerstrebungIrrigidimento:No
Cross over chamberKammer für FrequenzweicheVolume separato per filtro:No
Frequency rangeFrequenzgangRisposta in frequenza:50Hz - 20kHz ± 2dB
Bass CabinetBass GehäuseCabinet dei bassi:Bass Reflex
PortingBass ReflexCanaleRearNach hintenPosteriore
WooferTiefmitteltönerWoofer:170mm / 6,5"
MaterialMaterialMateriale:Peek-Carbon
P2C® Sandwich
Cross over frequencyÜbergangsfrequenzFrequenza di taglio:1800 Hz
MidhighMittelhochtönerMedioalti:Compression driverKompressionstreiberDriver a compressione
Horn ThroatHornDiametro tromba:1"
Membrane dimensionsMembranendimensionDimensione Membrana:35mm / 1,4"
MaterialMaterialMateriale:Mylar
Max power inputBelastbarkeitPotenza massima (RMS):100 W RMS
EfficiencyWirkungsgradEfficienza:88 dB
ImpedanceImpedanzImpedenza:8 Ohm
Impedance linearizationImpedanzlinearisierungLinearizzazione d'impedenza:No
TerminalAnschlussfeldTerminaliSingle-Wiring
MaterialMaterialMateriale:Gold plated copperVergoldetes KupferRame placcato oro
FeetsFüßePiedi:No
DimensionsMaßenDimensioni:480 x 220 x 320 mm
19 x 8,5 x 12,5 in
WeightGewichtPeso:7 kg
Center LoudspeakersCenter LautsprecherDiffusori centrali:Center 17
Center 15

Dimensions of the Genuin FS 5

Abmessungen der Genuin FS 5

Ingombri della Genuin FS 5

Options of the Genuin FS 5

Optionen der Genuin FS 5

Opzioni della Genuin FS 5

In our workshop we can offer all true-wood veneers.
Standard are Walnut and Cherry.
Here You can find some non exhaustive samples of the veneers.
As an option is matt lacquering possible as well.

Picture Gallery of the Genuin FS 5

Fotos der Genuin FS 5

Immagini della Genuin FS 5

Home Cinema Components for the Genuin FS 5

Heimkino Komponenten fr die Genuin FS 5

Componenti Home Cinema per la Genuin FS 5

Note:

Anmerkung:

Nota:

Note:

Wood is a natural product and depending on several factors might have different color and structure. Color and structure variations of the surface are not to be considered flaws.

Reviews
of the Genuin FS 5

Reviews
der Genuin FS 5

Tests
della Genuin FS 5


    Alt image
    Relative Dimensions Genuin FS 5
