Genuin CS 2 - Twin


Alt image
Blumenhofer Acoustics Genuin FS 1 Center
The Genuin CS 2 Center is based on the same components of the Genuin FS 2 and gives an optimal voice reproduction for your home cinema.
Der Genuin CS 2 Center Lautsprecher baut auf die elektrischen Komponenten der Genuin FS 2 mit ihren Vorzügen von Musikalität und Dynamik. Mittelpunkt dieser Entwicklung ist die Sprachwiedergabe und dient dazu das perfekte Heimkino Gefühl zu vermitteln: Mittendrin statt nur dabei!
Il diffusore centrale Genuin CS 2 Center è fatto sulla stessa base della Genuin FS 2 e dà una riproduzione sonora della voce ottimale per l’abbinamento al vostro home cinema.
Il carattere sonoro e la dinamica presentano una scena sonica in grado di sbalordire per omogeneità e intelligibilità.
Un’esperienza sonica eccezionale.

Specifications of the Genuin CS 2 - Twin

Spezifikationen der Genuin CS 2 - Twin

Specifiche della Genuin CS 2 - Twin

High efficiency

Cabinet


• Rear ported bass reflex cabinet
• 25mm Birch Multiplex
• D'Appolito configuration
• Separate Chamber for Crossover
• Resonance and flow optimized bass reflex Tunnel


Components


• 1.4" Compression Driver with Titan membrane
• 2x 30cm (12") Woofer with Paper Membran
• Gold plated tellurium copper terminals

Features


• Single-wiring-terminals
Tube Friendly
• 10 years Warranty
Hoher Wirkungsgrad

Gehäuse


• Nach hinten gerichtetes Bass Reflex Gehäuse
• 25mm Birch Multiplex
• D'Appolito Anordnung
• Getrennte Kammer für Frequenzweiche
• Resonanz- und strömungsoptimiertes hornförmiges Bass-Reflex Tunnel

Komponenten


• 1.4” Kompressionstreiber mit Titanmembran
• 2x 30cm (12”) Woofer mit Papier Membrane
• Vergoldete Tellurium Kupfer Anschlüsse

Eigenschaften


• Single-wiring-Anschlüsse
Rörenfreundlich
• 10 Jahre Garantie
Alta efficienza

Cabinet


• Cabinet con bass reflex posteriore
• Multistrato di betulla da 25mm
• Configurazione d'Apposito
• Camera separata per il filtro
• Tunnel di bass reflex ottimizzato per flusso e risonanza

Componenti


• Driver a compressione da 1.4" con membrana in Titanio
• 2x Woofer da 30cm (12") con membrana in carta
• connettori in rame tellurio placcato oro

Proprietà


• Terminali Single-Wiring
Ideale per valvole
• 10 anni di garanzia

Technical data of the Genuin CS 2 - Twin

Technische Daten der Genuin CS 2 - Twin

Dati tecnici della Genuin CS 2 - Twin

Center 25Center 20Center 17Center 15
Center 25Center 20Center 17Center 15
MaterialMaterialMaterialeBirch plywoodBirke MultiplexMultistrato di betullaBirch plywoodBirke MultiplexMultistrato di betullaMDFMDF
ThicknessMaterialdickeSpessore25mm / 1"25mm / 1"19mm / 0,75"19mm / 0,75"
Frequency rangeFrequenzgangRisposta in frequenza35Hz - 20kHz ± 2dB50Hz - 20kHz ± 2dB60Hz - 20kHz ± 2dB60Hz - 20kHz ± 2dB
Bass CabinetBass GehäuseCabinet dei bassiBass ReflexBass ReflexClosed cabinetGeschlossenes GehäuseCabinet chiusoClosed cabinetGeschlossenes GehäuseCabinet chiuso
PortingBass ReflexCanaleRearNach hintenPosterioreRearNach hintenPosterioreNoNo
WooferTiefmitteltönerWoofer2x 250mm / 10"2x 200mm / 8"2x 170mm / 6,5"2x 150mm / 5"
Woofer membraneBassmembraneMembrana del wooferPaper
P2F® Sandwich
Papier
P2F® Sandwich
Carta
Sandwich P2F®
Paper
P2F® Sandwich
Papier
P2F® Sandwich
Carta
Sandwich P2F®
Peek-Carbon
P2C® Sandwich
Peek-Carbon
P2C® Sandwich
Cross over frequencyÜbergangsfrequenzFrequenza di taglio1100 Hz1150 Hz1800 Hz1800 Hz
MidhighMittelhochtönerMedioaltiCompression driverKompressionstreiberDriver a compressioneCompression driverKompressionstreiberDriver a compressioneCompression driverKompressionstreiberDriver a compressioneCompression driverKompressionstreiberDriver a compressione
Horn ThroatHornDiametro tromba1.4"1"1"1"
Tweeter membraneMittelhochtönmembraneMembrana dei medioalti75mm / 3"44mm / 1,75"35mm / 1,4"35mm / 1,4"
MaterialMaterialMateriale TitaniumTitanTitanioMylarMylarMylar
Max power input (RMS)Belastbarkeit (RMS)Potenza massima (RMS)300 W RMS150 W RMS100 W RMS100 W RMS
EfficiencyWirkungsgradEfficienza94 dB92 dB88 dB88 dB
ImpedanceImpedanzImpedenza4 Ohm8 Ohm8 Ohm8 Ohm
TerminalAnschlussfeldterminaliBi-WiringSingle-WiringSingle-WiringSingle-Wiring
MaterialMaterialMaterialeGold plated tellurium copperVergoldetes tellurium KupferRame tellurio placcato oroGold plated tellurium copperVergoldetes tellurium KupferRame tellurio placcato oroGold plated copperVergoldetes KupferRame placcato oroGold plated copperVergoldetes KupferRame placcato oro
DimensionsMaßenDimensioni[mm]1000 x 500 x 330mm670 x 450 x 252600 x 450 x 195570 x 260 x 170
DimensionsMaßenDimensioni[Inches]39.4 x 19.7 x 1326.4 x 17.7 x 9.923.6 x 17.7 x 7.722.5 x 10.2 x 6.7
Dimensions Center 25Dimensions Center 20Dimensions Center 17Dimensions Center 15
WeightGewichtPeso45 kg30 kg25 kg10,4 kg
Packaging dimensionsVerpackungsmaßenDimensioni imballate88 x 63 x 38 cm69 x 43 x 36 cm
Loudspeakers per cartonLautsprecher per KartonPezzi pro cartone1111
Packaging weightVerpackungsgewichtPeso imballate50 kg32 kg28 kg12,5 kg
Related mainsPassende HauptlautsprecherDa abbinare aGenuin FS 1Genuin FS 1Genuin FS 3Genuin Bookshelf
Genuin FS 2Genuin FS 2Genuin BookshelfTempesta 20
Genuin FS 3Genuin FS 3Tempesta 20Tempesta 17
-Genuin BookshelfTempesta 17Tempesta Bookshelf
-Tempesta 20Tempesta Bookshelf-

Dimensions of the Genuin CS 2 - Twin

Abmessungen der Genuin CS 2 - Twin

Ingombri della Genuin CS 2 - Twin

Options of the Genuin CS 2 - Twin

Optionen der Genuin CS 2 - Twin

Opzioni della Genuin CS 2 - Twin

In our workshop we can offer all true-wood veneers.
Standard are Walnut and Cherry.
Here You can find some non exhaustive samples of the veneers.
As an option is matt lacquering possible as well.
In unserer hauseigenen Schreinerei können wir sämtliche Echtholzfurniere anbieten.
Standardfurniere sind Walnuss und Kirsche.
Hier gibt es ein Paar Beispiele der möglichen Furniere.
Optional ist auch eine Seidenmatt Lackierung möglich.
Nella nostra falegnameria possiamo produrre qualunque tipo di finitura superficiale in nobilitato di autentico legno.
Standard sono Noce e Ciliegio.
In questa pagina è possibile vedere alcuni esempi di nobilitature.
È anche possibile avere anche una verniciatura superficiale opaca.

Picture Gallery of the Genuin CS 2 - Twin

Fotos der Genuin CS 2 - Twin

Immagini della Genuin CS 2 - Twin

Note:

Anmerkung:

Nota:

Note:

In our workshop we can offer true-wood veneers.
Wood is a natural product and depending on several factors might have different color and structure. Color and structure variations of the surface are not to be considered flaws.
