On Wall 20
On Wall 20
On Wall 20
![]() ![]() |
The On Wall 20 loudspeaker bases on the electrical components of the Genuin FS 3 and the Tempesta 20 with their speed and dynamic. Die On Wall 20 Lautsprechern bauen auf die elektrischen Komponenten der Genuin FS 3 und der Tempesta 20 mit ihren Vorzügen von Musikalität und Dynamik. |
Specifications of the On Wall 20
Spezifikationen der On Wall 20
Specifiche della On Wall 20
• High efficiency
• 2-Ways loudspeaker
• Rear ported bass refles
• 18mm Birch plywood
• 1" Compression Driver with Mylar membrane
• 20cm (8") Woofer with P2F® Membran
• Gold plated terminals
• Single-wiring-terminals
• Tube Friendly
• 10 years Warranty
• 2-Ways loudspeaker
Cabinet
• Rear ported bass refles
• 18mm Birch plywood
Components
• 1" Compression Driver with Mylar membrane
• 20cm (8") Woofer with P2F® Membran
• Gold plated terminals
Features
• Single-wiring-terminals
• Tube Friendly
• 10 years Warranty
• Hoher Wirkungsgrad
• 2-Wege Lautsprecher
• Bass Reflex Gehäuse
• 18mm Birke-Multiplex-Echtholz
• 1” Kompressionstreiber mit Mylarmembran
• 30cm (8”) Woofer mit P2F® Membrane
• Vergoldete Tellurium Kupfer Anschlüsse
• Single-wiring-Anschlüsse
• Rörenfreundlich
• 10 Jahre Garantie
• 2-Wege Lautsprecher
Gehäuse
• Bass Reflex Gehäuse
• 18mm Birke-Multiplex-Echtholz
Komponenten
• 1” Kompressionstreiber mit Mylarmembran
• 30cm (8”) Woofer mit P2F® Membrane
• Vergoldete Tellurium Kupfer Anschlüsse
Eigenschaften
• Single-wiring-Anschlüsse
• Rörenfreundlich
• 10 Jahre Garantie
• Alta efficienza
• Diffusore a 2 vie
• Cabinet bass reflex
• Legno multistrato di betulla da 18mm
• Driver a compressione da 1 pollice con membrana in Mylar
• Woofer da 20cm (8") con membrana P2F®
• connettori placcati oro
• Terminali Single-Wiring
• Ideale per valvole
• 10 anni di garanzia
• Diffusore a 2 vie
Cabinet
• Cabinet bass reflex
• Legno multistrato di betulla da 18mm
Componenti
• Driver a compressione da 1 pollice con membrana in Mylar
• Woofer da 20cm (8") con membrana P2F®
• connettori placcati oro
Proprietà
• Terminali Single-Wiring
• Ideale per valvole
• 10 anni di garanzia
Technical data of the On Wall 20
Technische Daten der On Wall 20
Dati tecnici della On Wall 20
Surround 20 | Surround 17 | On Wall 20 | On Wall 17 | |
---|---|---|---|---|
![]() | ![]() | ![]() | ![]() | |
MaterialMaterialMateriale | MDF | MDF | MDF | MDF |
ThicknessMaterialdickeSpessore | 19mm / 0,75" | 19mm / 0,75" | 19mm / 0,75" | 19mm / 0,75" |
Frequency rangeFrequenzgangRisposta in frequenza | 50Hz - 20kHz ± 2dB | 50Hz - 20kHz ± 2dB | 50Hz - 20kHz ± 2dB | 60Hz - 20kHz ± 2dB |
Bass CabinetBass GehäuseCabinet dei bassi | Bass Reflex | Closed cabinetGeschlossenes GehäuseSospensione pneumatica | Bass Reflex | Closed cabinetGeschlossenes GehäuseSospensione pneumatica |
PortingBass ReflexCanale | FloorZum BodenA pavimento | - | RearNach hintenPosteriore | - |
WooferTiefmitteltönerWoofer | 200mm / 8" | 170mm / 6,5" | 200mm / 8" | 170mm / 6,5" |
MaterialMaterialMateriale | Paper P2F® SandwichPapier P2F® SandwichCarta Sandwich P2F® | Peek-Carbon P2C® Sandwich | Paper P2F® SandwichPapier P2F® SandwichCarta Sandwich P2F® | Peek-Carbon P2C® Sandwich |
Cross over frequencyÜbergangsfrequenzFrequenza di taglio | 1200 Hz | 1800 Hz | 1150 Hz | 1800 Hz |
MidhighMittelhochtönerMedioalti | Compression driverKompressionstreiberDriver a compressione | DomeKalotteCalotta | Compression driverKompressionstreiberDriver a compressione | Compression driverKompressionstreiberDriver a compressione |
Horn ThroatHornDiametro tromba | 1" | - | 1" | 1" |
Membrane dimensionsMembranendimensionDimensione Membrana | 44mm / 1,75" | 19mm / 0,75" | 44mm / 1,75" | 35mm / 1,4" |
MaterialMaterialMateriale | Mylar | SilkSeideSeta | Mylar | Mylar |
Max power input (RMS)Belastbarkeit (RMS)Potenza massima (RMS) | 150 W RMS | 100 W RMS | 150 W RMS | 100 W RMS |
EfficiencyWirkungsgradEfficienza | 90 dB | 88 dB | 90 dB | 88 dB |
ImpedanceImpedanzImpedenza | 8 Ohm | 8 Ohm | 8 Ohm | 8 Ohm |
TerminalAnschlussfeldTerminali | Single-Wiring | Single-Wiring | Single-Wiring | Single-Wiring |
MaterialMaterialMateriale | Gold plated tellurium copperVergoldetes tellurium KupferRame tellurio placcato oro | Gold plated tellurium copperVergoldetes tellurium KupferRame tellurio placcato oro | Gold plated copperVergoldetes KupferRame placcato oro | Gold plated copperVergoldetes KupferRame placcato oro |
FeetsFüßePiedi | No | No | ||
DimensionsMaßenDimensioni[mm] | 300 x 200 x 1000 mm 11.8 x 7.9 x 39.4 in | 300 x 125 x 470 mm 11.8 x 4.9 x 18.5 in | ||
![]() | ![]() | ![]() | ![]() | |
WeightGewichtPeso | 19,5 kg | 8 kg | ||
Packaging dimensionsVerpackungsmaßenDimensioni imballate | 105 x 60 x 38 cm | 69 x 43 x 36 cm | ||
Loudspeakers per cartonLautsprecher per KartonPezzi pro cartone | 2 | 2 | ||
Packaging weightVerpackungsgewichtPeso imballate | 42 kg | 18 kg |
Dimensions of the On Wall 20
Abmessungen der On Wall 20
Ingombri della On Wall 20
Options of the On Wall 20
Optionen der On Wall 20
Opzioni della On Wall 20
In our workshop we can offer all true-wood veneers.
Standard are Walnut and Cherry.
Here You can find some non exhaustive samples of the veneers.
As an option is matt lacquering possible as well.
Standard are Walnut and Cherry.
Here You can find some non exhaustive samples of the veneers.
As an option is matt lacquering possible as well.
In unserer hauseigenen Schreinerei können wir sämtliche Echtholzfurniere anbieten.
Standardfurniere sind Walnuss und Kirsche.
Hier gibt es ein Paar Beispiele der möglichen Furniere.
Optional ist auch eine Seidenmatt Lackierung möglich.
Standardfurniere sind Walnuss und Kirsche.
Hier gibt es ein Paar Beispiele der möglichen Furniere.
Optional ist auch eine Seidenmatt Lackierung möglich.
Nella nostra falegnameria possiamo produrre qualunque tipo di finitura superficiale in nobilitato di autentico legno.
Standard sono Noce e Ciliegio.
In questa pagina è possibile vedere alcuni esempi di nobilitature.
È anche possibile avere anche una verniciatura superficiale opaca.
Standard sono Noce e Ciliegio.
In questa pagina è possibile vedere alcuni esempi di nobilitature.
È anche possibile avere anche una verniciatura superficiale opaca.
Note:
In our workshop we can offer true-wood veneers.
Wood is a natural product and depending on several factors might have different color and structure. Color and structure variations of the surface are not to be considered flaws.
Wood is a natural product and depending on several factors might have different color and structure. Color and structure variations of the surface are not to be considered flaws.
