Gioia 2x220
Compact and powerful front horn
In a rationalisation attempt to rationalise our product portfolio, we simply decided to rename the Corona 2x220 into Gioia 2x220. Nothing else happened.
It is the same with two 20cm proprietary woofer in an horn loaded construction to increase their speed and their efficiency.
This project could not miss a powerful mid high range horn with all the knowledge gained in the last years. A successful speaker with unmatched qualities of compactness and richness of music
It is the same with two 20cm proprietary woofer in an horn loaded construction to increase their speed and their efficiency.
This project could not miss a powerful mid high range horn with all the knowledge gained in the last years. A successful speaker with unmatched qualities of compactness and richness of music
Specifications
• High efficiency
• 2-Ways loudspeaker
• Bassreflex cabinet with midrange horn
• New waveformer technology
• Front ported Bass-Reflex
• Resonance and flow optimised bass reflex
• Harmonic construction
• 1.4” Compression Driver with Titan membrane
• 2x 220mm (8") P2F Woofer
• Gold plated tellurium copper terminals
• Bi-wiring- / Bi-amping -terminals
• Time aligned
• Switchable impedance linearisation for the crossover frequency
• Tube Friendly
• 5 years Warranty
• 2-Ways loudspeaker
Cabinet
• Bassreflex cabinet with midrange horn
• New waveformer technology
• Front ported Bass-Reflex
• Resonance and flow optimised bass reflex
• Harmonic construction
Components
• 1.4” Compression Driver with Titan membrane
• 2x 220mm (8") P2F Woofer
• Gold plated tellurium copper terminals
Features
• Bi-wiring- / Bi-amping -terminals
• Time aligned
• Switchable impedance linearisation for the crossover frequency
• Tube Friendly
• 5 years Warranty
Technical Data
| Gioia Colossal | Gran Gioia MK 3 | Gioia 2x220 | |
|---|---|---|---|
| MaterialMaterialMateriale | Birch plywoodBirke MultiplexMultistrato di betulla | Birch plywoodBirke MultiplexMultistrato di betulla | Birch plywoodBirke MultiplexMultistrato di betulla |
| Horn MaterialHorn MaterialMateriale della tromba | HDF-Complex | HDF-Complex | HDF-Complex |
| ThicknessMaterialdickeSpessore | 19mm / 3/4" | 19mm / 3/4" | 19mm / 3/4" |
| Internal BracingVerstrebungIrrigidimento | Structural bracing interactionStrukturelle interaktionInterazione strutturale | Structural bracing interactionStrukturelle interaktionInterazione strutturale | Structural bracing interactionStrukturelle interaktionInterazione strutturale |
| Frequency rangeFrequenzgangRisposta in frequenza | 32Hz - 22kHz ± 2dB | 35Hz - 20kHz ± 2dB | 36Hz - 20kHz ± 2dB |
| Membrane dimensionsMembranendimensionDimensione Membrana | 2x 25cm / 10" | 380mm / 15" | 2x 20cm / 8" |
| MaterialMaterialMateriale | Paper P2F® SandwichPapier P2F® SandwichCarta Sandwich P2F® | PaperPapierCarta | Paper P2F® SandwichPapier P2F® SandwichCarta Sandwich P2F® |
| Bass CabinetBass GehäuseCabinet dei bassi | HornHornTromba Bass Reflex Harmonic | HornHornTromba Bass Reflex Harmonic | HornHornTromba Bass Reflex Harmonic |
| PortingBass ReflexCanale Reflex | FloorZum BodenA pavimento | FloorZum BodenA pavimento | FloorZum BodenA pavimento |
| Horn loadHorn RichtungCarico a tromba | FrontNach vorneAnteriore | FrontNach vorneAnteriore | FrontNach vorneAnteriore |
| Cross over frequencyÜbergangsfrequenzFrequenza di taglio | 850 Hz / 15.000kHz | 850 Hz | 850 Hz |
| Compression driverKompressionstreiberDriver a compressione | Compression driverKompressionstreiberDriver a compressione | Compression driverKompressionstreiberDriver a compressione | |
| Horn ThroatHornDiametro tromba | 1,4" | 1,4" | 1,4" |
| Membrane dimensionsMembranendimensionDimensione Membrana | 75mm / 3" | 75mm / 3" | 75mm / 3" |
| MaterialMaterialMateriale | TitaniumTitanTitanio | TitaniumTitanTitanio | TitaniumTitanTitanio |
| SeriesSeriedi Serie | OptionalOptionOpzione | Not AvailableNicht verf?gbarNon disponibile | |
| Compression driverKompressionstreiberDriver a compressione | Compression driverKompressionstreiberDriver a compressione | - | |
| Horn ThroatHornDiametro tromba | 1" | 1" | - |
| Membrane dimensionsMembranendimensionDimensione Membrana | 36mm / 1.4" | 36mm / 1.4" | - |
| MaterialMaterialMateriale | HT Polymer | HT Polymer | - |
| Max power input (RMS)Belastbarkeit (RMS)Potenza massima (RMS) | 300 W RMS | 150 W RMS | 300 W RMS |
| EfficiencyWirkungsgradEfficienza | 98 dB | 100 dB | 96 dB |
| ImpedanceImpedanzImpedenza | 4 Ohm | 8 Ohm | 4 Ohm |
| Impedance linearizationImpedanzlinearisierungLinearizzazione d'impedenza | YesJaSi | YesJaSi | YesJaSi |
| TerminalAnschlussfeldTerminali | Bi-Amping | Bi-Amping | Bi-Amping |
| MaterialMaterialMateriale | Gold plated tellurium copperVergoldetes tellurium KupferRame tellurio placcato oro | Gold plated tellurium copperVergoldetes tellurium KupferRame tellurio placcato oro | Gold plated tellurium copperVergoldetes tellurium KupferRame tellurio placcato oro |
| FeetsFüßePiedi | Adjustable SpykesRegelbare SpykesSpykes regolabili | Adjustable SpykesRegelbare SpykesSpykes regolabili | Adjustable SpykesRegelbare SpykesSpykes regolabili |
| DimensionsMaßenDimensioni | 1610x454x583 | 1335 x 550 x 840 mm | 450 x 630 x 1130 mm 17.75 x 24.8 x 44.5 in |
| WeightGewichtPeso | 80kg | 100 kg | 60kg |
| Packaging DimensionsVerpackungs MaßenDimensioni imballate | 2x 94x64x128 cm 1x 120x60x49 cm | 2x 94x64x128 cm 1x 120x60x49 cm | 2x 70x60x103 cm 1x 39x39x115 cm |
| Gross WeightGewicht verpacktPeso imballate | 2x 85kg 1x 35kg | 2x 75kg 1x 35kg | 2x 45 kg 1x 25kg |
Note:
In our workshop we can offer true-wood veneers.
Wood is a natural product and depending on several factors might have different color and structure. Color and structure variations of the surface are not to be considered flaws.
Wood is a natural product and depending on several factors might have different color and structure. Color and structure variations of the surface are not to be considered flaws.
Dimensions
